1. We CEEC TRUCKS are manufacturer, specializing in producing High Pressure Jetting truck many years with good reputation.
2. The CEEC High 8CBM Pressure Jetting truck also named High-Pressure road washer. Which washes the duty on the road, then takes it away through the drainpipe. This type high pressure jetting truck is with multi-function patterns and widely used for environmental protection city works and green belt.
3. Standard steel (Carbon steel Q235 & Q345, also the Stainless steel can be choose) for the tank, against corrosion resistant, rust protection and well-resisting.
4. The figure is flat ellipse. The transition of tank and side is by round arc, together with quality print, which makes the whole vehicle harmonious and good looking.
5. CEEC TRUCKS 8000Liters high pressure jetting trucks use the domestic initiate cleaning mode of high-pressure washing function and watering washing function to adapt to the different road cleaning. Also these two functions can operate together and also can operate separately.
6. CEEC TRUCKS high pressure jetting trucks equipped with pipe defroster device to avoid the watercourse freeze and damage the water spray system.
7. Water tank is equipped with low water level sensor alarm system, alarm automatically when water level is low.
8. Options for choose: Washing road surface, Multi-angle high intensive sullage cleaning, Highway railings washing, Spraying for adding humidity and reducing dust, Low & Flat high water flow washing, Road spray, right & left washing flowers, high-pressure spray gun for car washing, lift shaft, snow blade, front spray snow dissolving, standby for fire controlling. Customization is available.
Parameter |
|||
Truck Model |
CEEC5160GQX |
||
Tank Parameter |
Tank Capacity |
7CBM |
|
Tank Material |
Carbon Steel Q235 (Q345 for optional) |
||
Tank Shape |
Flat Ellipse Shape Tank |
||
Overall dimension (mm) |
Length |
8050 |
|
Width |
2490 |
||
Height |
3080 |
||
High Pressure Jetting |
Cleaning Speed (km/h) |
100 |
|
Cleaning Angel (°) |
30 |
||
Cleaning Width (mm) |
2.5-3.5 |
||
Max. Pressure (Mpa) |
10 |
||
Low Pressure Sprinkling |
Sprinkling Width (m) |
22 |
|
Speed (km/h) |
0-20 |
||
Water flow (L/min) |
600-900 |
||
Water canon shot range |
40 |
||
Chassis |
Chassis Brand |
DongFeng |
|
Drive Mode |
4x2 |
||
Tire type |
9.00-20 tire |
||
Tire No. |
6+1 units |
||
Max speed |
95 km/h |
||
Cab |
1. Flat roof, All-steel-welded construction 2. spring suspensions with hydraulic shock absorbers 3. Air condition 4. 2 seats 1-DIN AM/FM CD/MP3 Player |
||
Engine |
Power |
132 kw / 180hp |
|
Fuel type |
diesel |
||
Emission Standard |
Euro 3 & Euro 4 |
||
Gearbox |
Control type |
Manual |
|
Gear |
8 forward & 1 reverse |
CEEC High Pressure Jetting Washing System:
